6 ton Overhead Crane

We offer a wide range of 6-ton overhead cranes to cater to different applications. Our offerings include explosion-proof bridge cranes for coal mines, warehouse grab overhead cranes, warehouse electric single-girder overhead cranes, workshop single-girder overhead cranes, workshop grab overhead cranes, customized single-girder low-headroom overhead cranes, and grab bridge cranes. These cranes find applications in workshops, factories, warehouses, stockyards, and more, enabling efficient material lifting. Please note that the crane should not be used in flammable, explosive, or corrosive work conditions.


The 6 ton overhead crane system is composed of essential components that ensure seamless operation and reliable performance. It includes the main girder, electric hoist, traveling mechanism, and electric control devices. Noteworthy for its compact structure and robust rigidity, this crane offers numerous advantages. It is lightweight and compact, allowing efficient combination with electric hoists.


lifting-brake.jpgLifting mechanism brake

The hoisting mechanism motor equipped with double-disc electromagnetic brake. According to the safety regulations, SINOKO CRANE adopts the braking force of the brake higher than 1.8 times of the rated torque.

Fast movement and high reliability

Maintenance-free and self-regulated

Dustproof design and longer service life

drive-system.jpgABM three in one type drive

Drive mechanism is sealed three in one type.

Self-lubricatingMaintenance freeInverter control

Stable running

Reliable quality

Low noise

limit-Switch.jpgLimit SwitchThe hoist is equipped with the upper and lower end rotating chip circuit limiting device, and also can be selected with the touch top limit. At the same time, the machine is equipped with an overload protection device to ensure the safety of the operation.
crane-hook.jpgStandard swing hookThe hook can be freely rotated in the range of 360 degrees, vertical and 180 degrees, and the loading and unloading of the square change goods
hoist-cable-dragging-system.jpgHoist cable dragging system

Consisting of flexible flat cable, C-shaped steel slide

Flat cable with good flexibility

Aerial socket connecting, one to one correspondence, convenience of connection

Maintenance free, long operating life.



Unique Design Concept: The crane is designed with a unique concept that sets it apart from traditional cranes, providing distinct advantages.

Small Size and Light Weight: This crane is compact and lightweight, making it easier to maneuver and operate in various work environments.

Small Wheel Pressure: The crane exerts minimal pressure on the wheels, reducing the load on the supporting structure and allowing for more flexible installation options.

Reduced Clearance Height: The distance between the hook and the wall is minimized, resulting in a smaller minimum clearance height. This feature enables the crane to operate closer to the front of the operation, maximizing available workspace.

Increased Lifting Height: By utilizing the reduced clearance height, the crane offers the capability to lift materials to higher heights, enhancing overall lifting capacity.

Space Optimization: The crane's small size and light weight allow for the design of smaller plants without compromising functionality. This optimization helps save on construction costs and long-term maintenance expenses.

Enhanced Efficiency: The crane's unique design and features contribute to improved operational efficiency, enabling smoother material handling processes and increased productivity.

Versatility: The 6-ton overhead crane is versatile and can be used in various industries and applications, providing reliable and efficient lifting solutions.


Overall, the 6-ton overhead crane combines innovative design, compactness, and enhanced performance to offer a reliable and efficient solution for material handling tasks.


Product Model6 ton single girder overhead crane6 ton double girder overhead crane
Span6m - 31.5m10.5 - 34.5m
Lift height3m -80m3m -80m
Lifting Speed4/0.67 m/min4/0.67 m/min
Working DutyA5A5
Customized serviceProvidedProvided


Experience the benefits of the Sinoko European 6 ton Overhead Crane and take advantage of its unique features. Upgrade your material handling operations today and maximize your productivity and cost-efficiency.
