Hoist rope overhead cranes are designed to efficiently handle lifting tasks in industrial environments. Sinokocrane's hoist rope overhead cranes are engineered to meet the diverse needs of different industries. Whether it's a basic standard crane or a sophisticated advanced lifting system, Sinokocrane provides solutions that combine reliability, durability, and safety.
Types of Hoist Rope Overhead Cranes:
| General CD/MD Electric Hoist Rope Overhead Crane: These cranes feature a CD or MD electric hoist system and are suitable for various lifting applications in industries such as manufacturing, warehouses, and workshops. General CD/MD Electric Hoist Rope Overhead Crane, known for its economical nature, is a cost-effective solution for various industrial lifting needs. Capacity: 0.5~80t Lift Height: 3~35m or customized Span: 3~32m Protection class: IP44/IP54 Working temperature: -20~+40℃ |
| European Standard Hoist Rope Overhead Crane: Compliant with European standards, these cranes offer advanced features and precision, making them ideal for industries with strict lifting requirements such as aerospace, automotive, and heavy machinery. Compared with ordinary cranes, which has light weight about 10%~35%, wheel pressure can be reduced by about 10%~30%, and its height is also reduced a lot. Capacity: 1~80 tons Lift height: Max. 90 m Span: 7.5~40m Work duty: M3~M6 Protection class: IP54/IP55 Working temperature: -20~+60℃ |
(1) Long service life, high safety, never falling off;
(2) Small current, small size, strong output power, high frequency use;
(3) Beautiful appearance of the product, strong anti-corrosion;
(4) The product runs smoothly, heavy objects will not shake;
(5) Reduce factory height, save construction cost, increase effective work area and reduce customer investment;
(6) low noise, energy saving pipe environmental protection, light weight, safe and comfortable handling.
| Capacity/t | 2 | 3 | 5 | 8 | 10 |
| Span/m | 7.5-28.5 | 7.5-28.5 | 7.5-28.5 | 7.5-28.5 | 7.5-28.5 |
| lifting height/m | 9 | 9 | 9 | 9 | 9 |
| lifting speed m/min | 5/0.83 | 5/0.83 | 5/0.83 | 5/0.83 | 5/0.83 |
| Max.wheel load/kn | 14-28.5 | 18.5-34.4 | 25.2-46 | 43.5-66.5 | 50.5-77.8 |
| crane rail | P18(50*30) | P18/P24 | P24/P38 | P24/P38 | P24/P38 |
| Total power/kw | 2.7/3 | 4.5 | 5.5/5.9/6.2 | 10.6/10.9/12.1 | 10.9/11.2/12.1 |
| Dead weight/t | 1.5-7.6 | 1.6-7.8 | 2-9.4 | 2.6-10.6 | 2.6-11.9 |
| Note: the above data is only partial, can be customized products | |||||
Elevate your lifting operations with Sinokocrane's versatile hoist rope overhead cranes. Our comprehensive range of solutions, from general CD/MD electric hoist rope cranes to European standard cranes, ensures there is an ideal option for your specific industrial needs. Contact us today to discuss your requirements and discover how our hoist rope overhead cranes can optimize your lifting processes.
