European standard 5 ton Monorail Hoist Crane is belongs to light duty crane, can be used with single or double speed lifting hoist.
If the workshop clearance height is limited, the 5 ton Monorail Hoist Crane is recommended to save the above clearance space and below lifting height.
1. Low headroom
2. Smart driving, higher efficiency
3. Stepless control trolley
4. Hardened gear
5. IP55 Protection, F/ H Insulation
6. Heavy duty motor, 60%ED rating
7. Over heating, Overloading protect
8. Electromagnetic disk brake
9. Super drum, longer rope lifetime
10. DIN 34CrMo4 hook, Class T
11. Maintenance free
| Item | 5 ton monorail hoist crane |
| Main Electrical System | Schneider Brand |
| Frequency converter/VVVFDrive | Schneider Converter |
| Lifting mechanism | ABM/SEW Three in One Mechanism (Motor & Reducer & Brake) |
| Travelling Mechanism | DONLY Three in One Mechanism |
| Wire Rope | PFEIFER |
| Wire Rope Safety Factor | 5 times |
| Wire Rope Drum | Rolling Steel Plate |
| Bearing | SKF / drum, hook set, pulley. |
| Crane wheel | Forged type-42CrMo |
| Travelling cable | High Temperature Resistance |
| Buffer | CableBlack rubber buffer |
| Power Source/ Control Voltage | 380V 50HZ 4P AC/48Vw |
| Motor Insulation & StatorProtection | Class H & IP54 |
| Working Temperature | 60℃ |
| Cover Plate under Beam | Q345B |
| Main structure Steel material | Q235 |
| Painting | Shot blast Cleaning Dispose- 2 Grade, Epoxy Primer,Anti-corrosion Paint, Polyurethane surface painting |
| Safety Feature | Lifting and travelling limit switches; Emergency Stop; Loss voltage protection;Grounded protection; Overload protection ;Short circuit protection; Overheating protection; Over speed protection ;Over current protection; Faulted phase protection |
