Monorail EOT (Electric Overhead Traveling) Crane is a type of industrial crane that is designed to move along a single rail track, which is typically installed on the ceiling or a structure within a factory or warehouse.
The Monorail EOT Crane consists of a hoist trolley that moves along the monorail track, which is supported by a single girder that is suspended from the ceiling or structure. The hoist trolley can move in both the horizontal and vertical directions, and can lift loads up to 10 tons.
The construction of entire machine is simple, which is divided into four parts: main beam, end truck, lifting unit and electric controller on the foundation of the maximum function by minimum component. The entire machine is free from maintenance.
 |  |
| Overcapacity limit switch prevents the trolley lifting excessive overloads.- reeved to a low-headroom design lower block for minimum headroom and maximum lift | Oversized hand holes allow for easy access to connecon plate bolts - heavy duty bumper comes standard |
 |  |
| Variable frequency control provides controlled acceleration and deceleration for smoother operation- cables connect to bridge motors, power and pendant control for easy assembly | Totally enclosed helical bridge reducer motors are sized to provide better performance and longer life |
Advantages
Monorail EOT Crane has the advantages of compact dimensions, low building clearance, light weight, and low wheel pressure.
| Capacity （t） | Span(m) | Lifting Height(m) | Working Grade | lifting speed （m/min） |
| 2 | 6 | 6 | A5/2M | 0.7-8.2 |
| 9 | ||||
| 12 | ||||
| 15 | ||||
| 18 | ||||
| 21 | ||||
| 5 | 6 | 6 | A5/2M | 0.7-8.2 |
| 9 | ||||
| 12 | ||||
| 15 | ||||
| 18 | ||||
| 21 | ||||
| 10 | 6 | 9 | A5/2M | 0.3-3.3 |
| 9 | ||||
| 12 | ||||
| 15 | ||||
| 18 | ||||
| 21 |
The Monorail EOT Crane is a compact and flexible crane that provides efficient and reliable material handling solutions for various industries. If you're interested in obtaining a Monorail EOT Crane for your business, please don't hesitate to contact us for more information and a quote.
