Overview:
Experience the power and versatility of our 20 ton overhead crane, specifically designed for heavy-duty lifting and transportation in industries like steel, metallurgy, and building materials.
Choose from single or double girder configurations based on your lifting capacity and workspace constraints. Our overhead cranes provide robust performance, efficient operation, and enhanced productivity. Trust in our reliable solutions to optimize your material handling processes and ensure smooth operations in your industry.
Our bridge crane features a robust steel frame comprising a girder box, platform, pantograph, and trolley rail. The main girder undergoes precise fabrication and stringent testing to ensure compliance with design specifications and national standards. The fusion of toughness and strength creates an impeccable structure. We employ advanced welding techniques and equipment, utilizing carefully selected steel plates.
Additionally, the crane's surface undergoes shot blasting and high-quality painting, enhancing its durability and aesthetics. Trust in our commitment to delivering superior quality and performance in every aspect of our overhead crane design and manufacturing process.
Features
1). Light structure, easy installation and maintenance.
2). Reasonable structure, strong bearing capacity.
3). Low noise, soft starting and stopping.
4). Safe and reliable operation.
5). Low cost maintenance, long working life.
6). Strong box type, welding by machine hand.
7). Wheels, wire rope drum, gears, couplings are processed by CNC machine center, TOP quality control.
8). Heavy duty motor, or Sq.cage motor with VVVF, IP54 or IP44, insulation class F or H, soft starting and smooth running.
Specification
Lifting Capacity T | 5 | 10 | 16/3.2 | 20/5.0 | 25/5.0 | 32/5.0 | Oct-50 | |||
Span M | 10.5-31.5 | |||||||||
Lifting height M | Main Hook | 16 | 16 | 16 | 12 | 12/11.0 | 16 | 12 | ||
Aux Hook | 18 | 11 | 14/13 | 18 | 16 | |||||
Speed M/min | hoist | Main hook | A5 | 12.5 | 8.5 | 7.9 | 7.2 | 7.3 | 7.8 | 5.9 |
A6 | 15.5 | 13.3 | 13 | 9.7 | 9.8 | 9.5 | 7.8 | |||
Aux hook | 14.5 | 12.7 | 12.7 | 19.5 | 13.2 | |||||
Trolley travelling | 37.2 | 43.8 | 44.6 | 44.6 | 37 | 42.4 | 38.5 | |||
Bridge travelling | A5 | 89.8 /92.3 | 89.8-91.9 | 84.7-87.6 | 84.7/ 87.6 | 85.5/88 | 74.2-87.6 | 74.6 | ||
A6 | 116.2/ 117.4 | 112.5-116.8 | 112.5 | 112.5/ 101.4 | 112/ 101.4 | 86.8-101.4 | 87.3 | |||
Weight Kg | Trolley | A5 | 2126 | 3424 | 6227 | 6856 | 7185 | 10877 | 15425 | |
A6 | 2224 | 3562 | 6427 | 7180 | 7856 | 11652 | 15765 | |||
Total Weight | A5 | 12715-31405 | 14270-34405 | 19128-39428 | 19947-41497 | 20795-42796 | 26901-52748 | 35317-64880 | ||
A6 | 12991-31596 | 14719-34699 | 20045-41315 | 20984-44225 | 22632-16324 | 28061-55272 | 36075-67242 | |||
Max Wheel Load KN | A5 | 74-125 | 102-160 | 141-205 | 163-231 | 185-255 | 237-327 | 333-450 | ||
A6 | 75-126 | 104-162 | 145-211 | 167-239 | 189-263 | 242-335 | 336-457 | |||
Rail recommended | Trolley | 15kg/m | 43kg/m | |||||||
Bridge | 43kg/m | QU70 | QU80 | |||||||
Power Source | 380V 50HZ 3Phase | |||||||||
Henan Sinoko Cranes Co,.Ltd is a modern manufacturing enterprise, we are China famous overhead crane supplier. Our company has always maintained on the concept of Continuous Creation, Constantly Surpass. Building the international level modern enterprise, use top level management, manufacturing top level products.
Experience the power and reliability of our 20 ton overhead crane. Contact us today to learn more and elevate your lifting capabilities in the steel, metallurgy, and building materials industries. Trust our commitment to superior quality and performance.
CASE
Discover how the Sinoko 20 Ton Overhead Crane has transformed operations for businesses worldwide. From improving lifting efficiency to enhancing safety, explore real-world case studies showcasing the crane’s impact across various industries. Learn more today!
Automotive Repair Facility in Russia 5 Ton Workshop Bridge Crane Project Case
The Sinoko crane, a 5-ton bridge crane tailor-made for a Russian customer's auto repair shop, has helped the customer solve the problem of lifting and transportation, improved the customer's work efficiency, and saved the customer's work costs.
Learn More Get a Quote
3× 5T European-Style Single-Girder Cranes for Kenyan Sugar Refinery
Sinoko cranes has designed three 5-ton bridge cranes for Kenyan customers, which have solved their problems. Come and contact Sinoko cranes to solve your lifting problems.
Learn More Get a Quote
32T Steel Coil Handling Crane Project Case
Sinoko Crane with years of experience in crane manufacturing and design, the steel coil handling crane has helped customers reduce costs and improve the efficiency of steel coil transportation.
Learn More Get a QuoteFAQs
The Sinoko 20 Ton Overhead Crane is designed to lift loads up to 20 tons, providing heavy-duty lifting capabilities for various industrial applications.
With proper maintenance, the Sinoko 20 Ton Overhead Crane is built to last for many years, offering durable performance in demanding environments.
The Sinoko 20 Ton Overhead Crane is ideal for industries such as manufacturing, construction, warehouses, and steel mills, providing efficient material handling solutions.
Yes, Sinoko Cranes offer customization options, allowing you to tailor the crane's specifications to meet your specific needs, such as lifting height, span, and more.
The Sinoko 20 Ton Overhead Crane comes equipped with advanced safety features like overload protection, emergency stop buttons, and limit switches to ensure safe operation.
Regular maintenance, including inspections of hoists, motors, and control systems, is recommended to keep your Sinoko 20 Ton Overhead Crane in optimal working condition. Refer to the user manual for detailed guidelines.
