Overview
QX Magnetic Overhead Crane mainly consists of bridge, crane traveling mechanism, trolley, electric equipment and electromagnetic chuck.
When used, the rotary part of the hanger of electromagnetic disk must be locked up with screws and no rotation is allowed.
The crane mainly relies on the magnet, using the electromagnetic principles, then through electricity and magnetic plate to suck the goods firmly hanging to the designated place.
Cut the electricity, steel and irons will be lay down. It is the most convenient crane to transfer the scattered sheet metal.
Application
QL Model Rotating electromagnetic hanging beam overhead crane is applicable to the fixed span at indoors or outdoors of steel mill, Shipyard, port, workshop,yard and storage, etc.
Crane with slewing carrier-beam
QL Model Rotating electromagnetic hanging beam overhead crane is widely used to transport, assemble, load and unload billet steel, waste steel and other magnetic materials at workshop, warehouses, and goods yard, etc.
QL Model Rotating electromagnetic hanging beam overhead crane is especially applicable to lift material or different specifications and which needs horizontal rotation. The carrier-beam is cross structure has a certain function of preventing swinging. The lower part of the carrier-beam can bring special lifting appliances, such as magnetic chuck and tongs, etc.
Features
Widely use in steel plants, melting plant, waste warehouse, billet processing workshop
High working efficiency, safe and reliable operation
This crane mainly consists of strong bridge beams, crane travelling mechanism, electric trolley and electric system and magnetic disk system, and could be classified into several working duties, e.g. A5, A6, A7, according to the working frequency and pure working time
It is special magnetic pole is suitable for round coil with different diameters; selection of electromagnet depends on the length of round coil. If the electromagnet is long enough at a time
Weight overload protection device Includes automatic stopping type lifting weight limiter and weight display device.
Lifting limit switch and traveling limit switch
Emergency stop system
Electrical protection
The main insulation switch, emergency stop switch, short circuit, Zero voltage protection, loss of field protection, Current overload protection, over speed protection, zero position protection
Phase sequence protection and adopted crane specially anti- vibration contactor etc.
Interlock device
It sets interlock device for the cabin door and the other door from cabin into bridge structure, when the door is opened, the crane cannot work.
Specification
Capacity | t | 10+10 | 12.5+12.5 | 13.5+13.5 | |
Span | m | 28.5 | |||
Lifting height | m | 16 | 10 | 13 | |
Working class | A6 | A7 | A7 | ||
Speed | Hoisting | m/min | 11.4 | ||
Rotation | 0.8r/min | ||||
Traveling of crab | 38 | ||||
Traveling of crane | 88 | ||||
Recommended rail | QU80 | ||||
Power supply | 3-Phase 380V 50HZ | ||||
Control way | Pendent line control, Cabin control and remote control | ||||
Working duty | A6/A7 |
CASE
Based on their intended use, overhead cranes can be classified into general-purpose cranes, steel mill cranes, and explosion-proof cranes. Each type is designed with specific working environments and load requirements in mind, ensuring safety and efficiency.
32T Steel Coil Handling Crane Project Case
Sinoko Crane with years of experience in crane manufacturing and design, the steel coil handling crane has helped customers reduce costs and improve the efficiency of steel coil transportation.
Learn More Get a QuoteInstallation of QZ-Type Grab Bucket Bridge Crane Project Case
The Sinoko QZ-Type Grab Bucket Bridge Crane was specially designed for a Brazilian client as a grab bucket crane, which significantly improved the client's work efficiency and received unanimous praise from the client.
Learn More Get a Quote3× 5T European-Style Single-Girder Cranes for Kenyan Sugar Refinery
Sinoko cranes has designed three 5-ton bridge cranes for Kenyan customers, which have solved their problems. Come and contact Sinoko cranes to solve your lifting problems.
Learn More Get a QuoteFAQs
Its electromagnetic system lifts scattered metal instantly - just power on to attract loads, power off to release. Beats hooks/chains for loose steel sheets or scrap.
Yes! Our 380V electromagnetic disks work in steel mills up to 150°C. For hotter zones (like near furnaces), we add heat shields at no extra cost.
Typically 12-14 weeks after order confirmation.
Automatic shutoff if lifting exceeds capacity;Emergency stop buttons on pendant/cabin;Power-loss safety (magnets release safely during outages)
All cranes come with CE, ISO, and SGS certificates. We test every unit for 48 hours before shipping.
16+ years specializing in magnetic cranes. We've installed 200+ units in steel mills and ports worldwide. Ask for our scrap yard case studies!
