FEM Standard Railway Gantry Crane is a specialized container handling equipment, which is widely used in loading and unloading of container yards such as coastal ports, inland ports, railway transit and chemical storage.

FEM Standard Railway Gantry Cranes are designed to maximize operational efficiency and minimize downtime, contributing to more productive and cost-effective operations.


Share With:


Railway Gantry Crane

FEM Standard Railway Gantry Crane can smoothly run on the ground track, which adopts a U-shaped gantry and has a large leg clearance (nearly 7m) and is suitable for loading and unloading of bulky and heavy cargoes and containers.

With features such as strong overload capacity, large working range, and work balance, it is suitable for large spans and frequent loading and unloading operations.

Which widely used in railway freight yards, ports, open storage, container transfer stations and etc.


rail-mounted gantry crane

Feature

(1)With features such as strong overload capacity, large working range, and work balance, it is suitable for large spans and frequent loading and unloading operations.

(2)With a large span, it can span 14 columns or more of containers with a large number of stacked layers, and can stack up to 5 to 6 containers.

(3)Applicable to container terminals with limited floor space and high throughput. Railway freight yards, ports, open storage, container transfer stations, etc.

(4)The mechanical structure is simple, maintenance is easy, and the operation is reliable. Walking along the track, poor flexibility, limited operating range.

(5)The utilization of the yard area is high, the stacking capacity of the storage yard is improved.


Specification


Lifting capacityt35
Spanm30
Lifting Heightm16
Workingsystem
A6(intermediate)

Load and unload of goods


20 , 40 containers
Speed
Hoistingm/min
0~10
crab travelling3.4~34

trolley travelling

2.9~29
Max.wheelloadKN295
Steel track reeomended
QU80
Power Source3-phase  AC.50Hz380V

Gantry Crane Cases Showing


Railway Container Gantry Cranes Case


Get a Free Quote

CASE

Discover how businesses worldwide use Sinoko cranes gantry crane to optimize operations. Explore real project examples across ports, rail terminals, and logistics hubs.

40.5T Rail-Mounted Gantry Crane Installation for Port Logistics Efficiency

40.5T Rail-Mounted Gantry Crane Installation for Port Logistics Efficiency

The RMG gantry crane designed and manufactured by Sinokocrane has effectively solved the problems for the customers and reduced their operational costs.

Learn More Get a Quote
5T Portable Gantry Crane Deployment for Australian Equipment Rental

5T Portable Gantry Crane Deployment for Australian Equipment Rental

The portable gantry cranes provided by Sinoko Cranes for the leasing company of Australian customers have significantly increased the number of rentals for the customers and enhanced the revenue of their companies.

Learn More Get a Quote
Pakistan Scrap Steel Dumping Container Gantry Crane Project Case

Pakistan Scrap Steel Dumping Container Gantry Crane Project Case

The Sinoko crane, leveraging years of experience and outstanding technology, designed a container gantry crane for customers, successfully solving the problem of transporting scrap steel for them.

Learn More Get a Quote

FAQs

1. What’s this crane designed for?

Specialized in handling containers and heavy goods, suitable for high-intensity loading and unloading scenarios in ports, railway yards, chemical storage areas, etc.

2. What’s its lifting capacity?

Standard lifting capacity: 35 tons (can support custom orders of 5-60 tons), capable of efficiently handling 20/40 foot containers.

3. Where can it operate?

Suitable for railway transfer stations, open-air storage yards, container terminals, etc. The working temperature range is -20°C to +40°C.

4. Does it require special infrastructure?

Ground tracks need to be laid (the QU80 type steel rails are recommended), and the power supply is 380V/50Hz three-phase alternating current.

5. What safety standards does it meet?

Compliant with international FEM standards, it is equipped with a mechanical anti-shake system to ensure safe and reliable operation during high-frequency operations.

6. Why choose Sinoko?

15 years of professional crane design experience, providing customized solutions and full-cycle services including installation and maintenance.
