LDA electric single beam overhead crane is a light and small lifting machine. Its lifting capacity is 1 Ton 2 Ton 3 Ton 5 Ton 10 Ton 15 Ton 20 Ton. The span is 7.5~31.5m, the working level is A3-A5, and the working environment temperature is -25℃~40℃. The hoisting mechanism has single speed CD1 electric hoist and double speed MD1 electric hoist. This product is widely used in factories, warehouses, material yards and other occasions to lift goods.
It is prohibited to use in flammable and explosive corrosive media environment. This product has two operation modes: ground and remote control.
Features
* Good design, strong rigidity, Compared with European designed cranes, LDA is more economical.
* Good stability, convenient in use and strong commonality.
* Steady travelling with speed adjusting function.
* Wide selection of electric hoists.
LDA Single Girder Overhead Crane Component
LDA Single Girder Overhead Crane usually consists of main beam, end beam, electric hoist, H-track, electrical components and control system. Cranes for single girder overhead crane are usually used with single or double speed lifting hoist or low clearance electric hoists, which include different types of single girder crane.
|
Main girder 1. with strong box type and standard camber. 2. there will have reinforcement plate inside the main girder |
|
Crane end beam 1.uses rectangular tube manufacturing module 2.buffer motor drive 3.with roller bearings and permanent iubrication； |
|
Electric hoist 1. Lifting Goods or materials； 2. Model CD1/MD1； |
|
Crane hook 1.Material：Carbon steel or alloy steel or custom required material 2.Grade：M /P /S /T /V grade 3.capacity:1-30t |
|
Remote controller 1. 2/4/6/8/10/12keys for choosing 2. voltage: as required； |
Specification
| Capacity | 1t to 20t |
| Working Duty | A3 |
| Max. Lifting Height | 32m |
| Max. Span | 35m |
| Control Method | Pendent Line Control+Radio Remote Control |
| Lifting Speed | 8/1.3 m/min |
| Traveling Speed | 30m/min |
| Power Supply | 380V 50Hz 3Phase or Customized |
| Main Electric Part | Schneider |
CASE
To help you better understand the reliability and performance of our LDA-type single girder overhead cranes, we’ve highlighted real-world project cases from our customers across various industries. These examples showcase how our cranes are tailored to meet different lifting requirements, environments, and operational demands. Explore the case studies below to see how Sinoko Crane delivers efficient and cost-effective lifting solutions worldwide.
5T LDA Single Beam Overhead Crane for Ethiopian Textile Factory
Boost your lifting efficiency with our 5T Single Girder Bridge Crane — reliable, durable, and built for performance. Perfect for workshops, warehouses, and industrial handling.
Learn More Get a Quote
3× 5T European-Style Single-Girder Cranes for Kenyan Sugar Refinery
Sinoko cranes has designed three 5-ton bridge cranes for Kenyan customers, which have solved their problems. Come and contact Sinoko cranes to solve your lifting problems.
Learn More Get a Quote
Automotive Repair Facility in Russia 5 Ton Workshop Bridge Crane Project Case
The Sinoko crane, a 5-ton bridge crane tailor-made for a Russian customer's auto repair shop, has helped the customer solve the problem of lifting and transportation, improved the customer's work efficiency, and saved the customer's work costs.
Learn More Get a QuoteFAQs
The LDA type single‑girder overhead crane ranges in lifting capacity from 1 ton up to 20 tons, with a span varying approximately between 7.5 m and 31.5 m—making it a versatile, light‑duty solution suitable for numerous industrial settings.
Customers can choose between single‑speed CD1 or double‑speed MD1 electric hoists. In terms of control, it supports ground‑mounted pendent line controls as well as radio remote control for flexible, efficient operation.
The crane is rated for working duty classes A3 to A5 and functions reliably in temperatures ranging from –25 °C to 40 °C. It is ideal for indoor use in factories, warehouses, or material yards—but not suitable for flammable, explosive, or highly corrosive environments.
Safety and performance are assured through high‑quality components and design: separate control for crane and hoist motions, smooth operation via flat‑cable or specialized cable systems, and reliable construction featuring galvanize slides, reinforced main girders, and standard electrical systems.
Yes—the LDA model delivers economic advantage without compromising structural integrity. Its simpler design leads to lower upfront costs while maintaining robustness for common light‑duty lifting tasks.
This crane excels in environments like production plants, storage facilities, and loading zones where goods must be lifted, moved, or placed. Its compact design, adaptable control, and dependable hoists make it a reliable daily workhorse for general material handling.
