LH model electric Hoist Overhead Crane has such features as tight dimensions,low building headroom,light dead weight and light wheel load.They are applicable to the transfer,check and repair as well as load and unload at mechanic processing workshop, subsidiary workshop of metallurgical mills,warehouse,goods yard and power station. They can also be used instead of common double-girder overhead crane at production workshkop in light textiles or food industry. It has two kinds of classification, that is,light and medium.The working ambient temperature is generally-25 DC to 40 DC. It is forbidden to work in environment with combustible, explosive or corrosive media.
（1) LH Type double girder overhead cranes are the ideal solution for the area coverage handling of heavy loads from 5t up to 32t.
（2) Like other kind of factory cranes, these cranes are available with installation on the new or existing buildings and the best in functionality, versatility and convenience.
（3) With advantages of compact structure, light dead weight, maximum lifting height, these cranes are widely used in workshop, metallurgical mills, warehouse, assembly shop etc.
Features
Control method:
The basic parameters should informed by the users, for the capacity, lifting speed and so on.
Specification
| lifting Weight | t | 5~32t | |
| Control model | Pendent Control & Cabin Control | ||
| Speed | Main Lifting | m/min | 3, 3/0.3 |
| Aux Lifting | 7,7/0.7 | ||
| Trolley Traveling | 20 | ||
| Long Traveling | 20 | ||
| Motor | Main Lifting | Type/Kw | ZD162-6/18.5 ZDS1-0.8/7.5 |
| Aux Lifting | ZD51-4/13 | ||
| Trolley Traveling | YDE100L-4/2.2*2 | ||
| Long Traveling | YDE100L-4/3*2 | ||
| Electric Hoist | Type | CD1-16 MD1-16 | |
| Lifting Height | m | 6,9,12,18 | |
| Working Duty | A3-A5 | ||
| Power Source | 3 Phase 50Hz 380V | ||
| Span | m | 10.5,13.5,16.5,19.5,22.5,25.5,28.5,31.5 | |
CASE
Based on their intended use, overhead cranes can be classified into general-purpose cranes, steel mill cranes, and explosion-proof cranes. Each type is designed with specific working environments and load requirements in mind, ensuring safety and efficiency.
3× 5T European-Style Single-Girder Cranes for Kenyan Sugar Refinery
Sinoko cranes has designed three 5-ton bridge cranes for Kenyan customers, which have solved their problems. Come and contact Sinoko cranes to solve your lifting problems.
Learn More Get a Quote
Automotive Repair Facility in Russia 5 Ton Workshop Bridge Crane Project Case
The Sinoko crane, a 5-ton bridge crane tailor-made for a Russian customer's auto repair shop, has helped the customer solve the problem of lifting and transportation, improved the customer's work efficiency, and saved the customer's work costs.
Learn More Get a Quote
Installation of QZ-Type Grab Bucket Bridge Crane Project Case
The Sinoko QZ-Type Grab Bucket Bridge Crane was specially designed for a Brazilian client as a grab bucket crane, which significantly improved the client's work efficiency and received unanimous praise from the client.
Learn More Get a QuoteFAQs
Standard orders ship in 10-12 weeks by sea.
Yes! Designed for tight spaces with minimal headroom. The compact design clears ceilings just 15% higher than your loads - ideal for retrofitting existing buildings.
Choose your control: → Pendant control (included) for basic operation → Wireless remote for freedom of movement → Cabin option for all-day use
Simple monthly checks: 1.Inspect wire ropes 2.Test limit switches 3.Lubricate wheelsWe provide a 3-minute video guide with every crane.
Operates reliably from -25°C to 40°C. Add our winter package (+$620) for: ✓ Anti-freeze grease ✓ Cold-rated electronics ✓ Non-slip platforms
Three key advantages: ① Precision control (±2cm positioning) ② 60% faster than chain hoists ③ Reduced operator fatigue
