Introducing our powerful and robust gantry crane with a massive lifting capacity of 275 tons. This heavy-duty crane is designed to handle the most demanding lifting operations in various industries. With its exceptional strength, reliability, and advanced features, it is the perfect solution for your large-scale material handling needs.
Main Girder and Support Leg of Gantry Crane 275 ton:
The main girder and Support Leg including the girder box, platform, pantograph and trolley rail. The Main girder and support leg will be strictly fabricated and detected in our workshop according the design and national standard. The toughness and strength are perfect combination; It adopts shot blasting and high quality painting. Well-chosen choose steel plate, advanced welding technology and equipment.
There are two type structure for the main girder and leg as optional:
1. Truss type advantage:
a. Small windward side and wind resistance
b. Light dead weight, Low cost
2. Box type advantage:
a. Compact structure, save shipping cost, indoor use available.
High Lifting Capacity: The gantry crane boasts an impressive lifting capacity of 275 tons, allowing you to lift and move heavy loads with ease. It is designed to handle even the heaviest and most challenging lifting tasks in industries such as construction, shipbuilding, mining, and more.
Sturdy Construction: Our gantry crane is built with a robust and durable structure, ensuring stability and safety during lifting operations. It is engineered to withstand heavy loads, harsh environmental conditions, and rigorous daily use, providing long-lasting performance and reliability.
Advanced Control System: Equipped with a state-of-the-art control system, our gantry crane offers precise and smooth operation. It features advanced safety features, including overload protection, emergency stop buttons, and comprehensive monitoring systems to ensure optimal safety for operators and the surrounding area.
Customizable Design: We understand that each lifting application is unique. Therefore, our gantry crane can be customized to meet your specific requirements. Whether you need a particular span length, adjustable lifting height, specialized lifting attachments, or additional features, our team can tailor the crane to your exact needs.
Ease of Mobility: Despite its massive lifting capacity, our gantry crane is designed for easy mobility. It be equipped with a track system, allowing smooth and efficient movement within your facility or worksite. This flexibility ensures optimal positioning and accessibility to the loads.
Sinoko Gantry Crane 275 ton Safety:
A: Strict Quality Control:
We have strong production capacity, perfect equipment, advanced technique and complete quality supervision system which includes welding quality supervision and inspection, structure quality supervision and inspection,static loading and dynamic loading test.
B. Safety Device:
Mechanical | Electrical | ||
No. | Item | No. | Item |
1 | Overload Limiter | 1 | Main isolating switch |
2 | Limit Switch (Lifting and Traveling) | 2 | Short-circuit protection |
3 | Interlock protection device | 3 | Under-voltage protection |
4 | Buffer | 4 | Zero protection |
5 | Rail tongs, Anchor device | 5 | Motor overload protection |
6 | Rail clear plate | 6 | Emergency stop system |
7 | Protective cover | 7 | Current overload protection system |
8 | Bus Bar preventer plate | 8 | Security chain protection |
9 | Anti-collision device | 9 | Ground protection |
10 | Anti-overturn Safety Device | ||
11 | Anemometer | ||
| Specification | Value |
| Lifting Capacity | 275 tons |
| Span Length | 30 meters |
| Lifting Height | 12 meters |
| Working Class | A6 |
| Control System | PLC Control |
| Power Supply | 3-phase, 380V |
| Crane Speed | Variable |
| Structure | Box-type girder |
| Mobility | Track |
| Safety Features | Overload protection, emergency stop, limit switches |
| Customization Options | Span length, lifting height, control system, additional safety features |
With its exceptional lifting capacity and versatile design, our gantry crane is ready to tackle the most demanding lifting tasks in your industry, providing efficient and reliable material handling solutions.
Our service for RMG Crane
Pre-sales service
1. Feedback your information within 24 hours.
2. Professional engineers provide drafts and solution ways.
3. Give satisfying advice.
Sales service
1. Provide different plans and required drafts.
2. Accept the service that customers pay a visit to our factory.
3. Flexible delivery ways and payments.
After-sales service
1. One year warranty.
2. Professional engineers take part in installations, equipment adjustment and training of workers.
3. Free repair and components if there is quality problem within quality deadline.
Upgrade your lifting capabilities with our high-performance gantry crane, capable of lifting 275 tons. Contact us today to discuss your specific requirements and benefit from our customizable and reliable lifting solutions. Experience the power, durability, and efficiency of our gantry crane for your heavy-duty material handling operations.
