Rail-mounted gantry crane (RMG) is a specialized type of gantry crane used for container handling purposes. It finds extensive applications in railway stations, ports, container yards, and similar environments.
The RMG crane operates by running along tracks, enabling it to lift, stack, or transfer containers within the designated area of a container yard or terminal.
The lifting mechanism and crane's travel system are commonly controlled using AC frequency conversion technology. This allows for precise control and efficient operation of the crane, enhancing productivity and safety in container handling operations.
Feature
Smooth operation, speed can be customized
Light Self Weight
Small Space Occupy
Low Cast of Running and Maintaining
High Working Duty
Safety and Reliable
The Benefits of Using Rail Mounted Gantry Cranes
Efficiency and Productivity
RMGs enhance operational efficiency as they can handle heavy loads swiftly and accurately. Their high-speed performance contributes to increased productivity within industrial settings.
Safety and Stability
RMGs are designed to be sturdy and stable. Their rail-based design reduces the risk of tipping over, making them safer to operate, especially when handling heavy or hazardous loads.
Versatility and Adaptability
Rail mounted gantry cranes are adaptable to various working conditions. Their height and span can be customized based on specific operational requirements.
Specification
| Capacity | t | 30 | 35 | 40.5 | 45 | 50 |
| Span | S(m) | 18~35 | 18~35 | 18~35 | 18~35 | 18~35 |
| Lifting height | m | 12.3~21 | 12.3~21 | 12.3~21 | 12.3~21 | 12.3~21 |
| Lifting speed | m/min | 12.5 | 9.5 | 10 | 9.8 | 9.2 |
| Trolley speed | m/min | 56 | 48 | 48 | 45 | 45 |
| Crane speed | m/min | 50 | 44.3 | 44.3 | 42 | 42 |
| Container | 20′ 40′ | 20′ 40′ 45′ | 20′ 40′ 45′ | 20′ 40′ 45′ | 20′ 40′ 45′ | |
| Work duty | A6~A8 | A6~A8 | A6~A8 | A6~A8 | A6~A8 | |
| Track type | QU80 | QU80 QU100 | QU80 QU100 | QU100 QU120 | QU100 QU120 | |
Factors Influencing the Price of Rail Mounted Gantry Cranes
Crane Specifications
The specifications of the RMG, including its capacity, height, and span, significantly affect its price. Higher specifications usually mean a higher price.
Manufacturer Reputation
The reputation and reliability of the manufacturer also influence the price. Renowned manufacturers might charge more for their products due to their established brand and proven track record of quality.
After-Sales Service
The quality of after-sales service, including installation, maintenance, and repair services, can also impact the price of the crane.
| Lifting Capacity Range | Price Range |
| 30-40 tons | $300,000 - $600,000 |
| 50-100 tons | $500,000 - $1 million |
Please note that these prices are average ranges and can vary based on various factors, as mentioned earlier.
If you're ready to invest in a rail-mounted gantry crane, why wait? Explore the industry-leading options provided by Kinocranes. Enjoy enhanced productivity, safety, and customization in your operations. Start improving your business today and get a free quote.
CASE
Explore how Sinoko RMG Cranes transform global container operations - from port efficiency gains to rail yard cost savings. Witness real-world performance metrics and engineering excellence in action.
Container Gantry Crane in Railway
Discover the efficiency of Sinoko's 40.5-ton container gantry crane in railway transfer freight yards. Enhance your container handling operations today—contact us for a consultation!
Learn More Get a Quote
Pakistan Scrap Steel Dumping Container Gantry Crane Project Case
The Sinoko crane, leveraging years of experience and outstanding technology, designed a container gantry crane for customers, successfully solving the problem of transporting scrap steel for them.
Learn More Get a Quote
40.5T Rail-Mounted Gantry Crane Installation for Port Logistics Efficiency
The RMG gantry crane designed and manufactured by Sinokocrane has effectively solved the problems for the customers and reduced their operational costs.
Learn More Get a QuoteFAQs
Rail yards & high-density ports - lower ground pressure, higher stability for 6-container stacking, and 30% less energy consumption.
500,000−800,000 (base model). Final cost depends on: Span length (18-35m)、Customizations (cantilevers/automation)、Duty class (A6-A8)
FEM-standard crane structure、AC frequency control system、9 safety features (anti-collision/overload cutoffs)、QU80 rail installation kit
14-18 weeks after order confirmation. On-site assembly in <7 days with our engineering team.
Yes - all models support 20ft/40ft/45ft containers. Specify spreader type when ordering.
✓ 30% cost advantage with same FEM standards ✓ Lifetime remote diagnostics ✓ Spare parts guarantee (48hr global delivery)
